Cold Storage Insulation in Pakistan 2026, PUF, PIR & EPS Sandwich Panels
Pakistan's cold chain sector is expanding fast, from KPK apple orchards to Sindh dates and citrus, Karachi's halal-meat export docks, and pharmaceutical cold storage nationwide. Behind every functioning cold room is one critical decision that determines both build cost and 25 years of electricity bills: the insulation panel core. At interiorsolutions.pk, we supply cold storage insulation panels and materials for chiller rooms, freezers, and walk-in coolers across Pakistan.
For smaller-scale insulation needs, see our Thermocol/EPS Sheet and PU Foam Spray guides, this page focuses specifically on structural cold storage panel construction.
PUF vs PIR vs EPS, The Core Decision for Cold Storage
Sandwich panels for cold storage come in three insulation core types, and the difference between them compounds every single day the facility runs:
EPS (Expanded Polystyrene) panels are the cheapest option upfront but carry real long-term costs. Higher thermal conductivity means more heat leaks in, so compressors run longer and electricity costs climb. EPS is also fire class E, increasingly refused by insurers and pharmaceutical buyers for that reason alone. EPS makes sense for: temporary storage, non-critical structures, or budget-constrained projects where 24/7 refrigeration efficiency isn't the priority.
PUF (Polyurethane Foam) panels sit in the middle, noticeably better insulation performance than EPS at a real but manageable price premium. PUF sandwich panels are well suited to small cold stores like walk-in coolers and walk-in freezers.
PIR (Polyisocyanurate) panels offer the best insulation performance and, critically, better fire resistance, PIR panels meet fire resistance-rated Class B1 (non-flammable) standards with self-extinguishing properties, making them the standard choice for large cold storage warehouses where fire safety requirements are strict, and increasingly the preferred choice for pharmaceutical and export-grade facilities.
Cold Storage Panel Price in Pakistan, 2026
| Panel Type | Price Range (per m², indicative) |
|---|---|
| EPS panel | PKR 2,800 – 3,500 (varies by thickness) |
| PUF panel | PKR 4,500 – 6,000 (varies by thickness) |
| PIR panel (50mm) | PKR 4,500 – 7,500 |
| PIR panel (100mm) | PKR 6,500 – 10,500 |
| PIR panel (150mm) | PKR 9,500 – 15,500 |
The relative cost pattern: PUF runs roughly 0.85× the PIR rate for equivalent performance; EPS runs roughly 0.60× the PIR rate, cheaper upfront but with the electricity and fire-safety trade-offs covered above.
Panel Thickness by Temperature Zone
Panel thickness must match your target storage temperature, undersizing thickness to save upfront cost is one of the most common and expensive mistakes in Pakistani cold storage projects:
| Temperature Zone | Recommended Thickness | Typical Use |
|---|---|---|
| Chiller (+2°C to +5°C) | 50-80mm | Fruit, vegetables, dairy |
| Standard freezer (−18°C to −25°C) | 100-150mm | General frozen goods |
| Deep freeze | 120-150mm | Extended frozen storage |
| Blast freezer (−40°C) | 150mm+ | Shrimp, plate-frozen fish, rapid carcass freezing |
| Controlled-atmosphere store (+1°C) | Roughly 30% above medium-temp | KPK apples, Sindh dates, premium citrus |
Have questions about this?
Chat with us on WhatsApp. We usually reply within minutes.
A 100mm panel cuts heat transmission load by roughly a third compared to a thinner alternative, the electricity savings over years of continuous operation typically far outweigh the higher upfront panel cost.
Turnkey Cold Storage Build Cost in Pakistan, 2026
For a complete picture beyond just panel material cost, indicative turnkey construction benchmarks (including panels, refrigeration plant, doors, and controls, civil works extra) run approximately:
| Cold Storage Type | Cost per m³ (PKR) |
|---|---|
| Chiller (+0°C to +5°C) | 18,000 – 45,000 |
| Standard freezer (−18°C to −25°C) | 25,000 – 77,500 |
| Blast freezer (−40°C) | 35,000 – 150,000 |
A pharmaceutical cold room requiring validation (redundancy, alarm logging, regulatory-compliant monitoring) typically carries a 25-40% premium over standard medium-temperature construction.
The Electricity Cost Reality, Why Panel Thickness Matters More Than the Purchase Price
Capital cost is the headline number buyers focus on, but electricity is the real long-term cost driver. At Pakistani industrial tariffs, operating cost over a facility's 25-year life routinely exceeds the original capital cost by 1.5-2× on a properly-loaded freezer.
The practical implication: saving money upfront by under-specifying panel thickness can cost significantly more in electricity over the facility's operating life than the initial savings were worth. Running the numbers on thickness options before committing to a build spec is genuinely worth the time investment.
Commonly Missed Line Items in Cold Storage Budgets
Beyond the panel and refrigeration plant cost, several items are frequently missed in initial budgeting:
Voltage stabilisation: Pakistani grid voltage swings will damage refrigeration compressors without proper stabilisation equipment, a genuine, non-optional line item for reliable operation.
Generator backup: sized for full plant load, this is essentially non-negotiable in most Pakistani cities given ongoing load-shedding, which otherwise directly threatens stored product during outages.
Door discipline consideration: every minute a cold storage door stays open during summer pumps in moisture and heat that the refrigeration plant then has to remove over an extended period, a factor worth accounting for in both facility design (air curtains, strip curtains) and operational protocol.
Related Pages
Get a Cold Storage Insulation Quote, Nationwide
WhatsApp: +923025102766
Email: interiorsolutions580@gmail.com
Material delivery: 2–5 working days · Project consultation available for larger builds
COD on eligible orders · JazzCash · Easypaisa · Bank Transfer
WhatsApp your target temperature, facility size, and sector (food, pharma, export), we recommend the right panel type and thickness for your project.
Ready to order?
Message us on WhatsApp for pricing, availability, and delivery.
Frequently Asked Questions
PUF panel prices in Pakistan run approximately PKR 4,500-6,000 per m² depending on thickness, sitting between EPS (cheaper but less efficient, PKR 2,800-3,500/m²) and PIR (better performance and fire resistance, PKR 4,500-15,500/m² depending on thickness) in the cost-performance spectrum. Thickness should be selected based on your target storage temperature, not just budget, given the long-term electricity cost implications of undersized insulation.
